PCC panels receive incoming power and distribute it to downstream loads and panels, with metering and protection at the primary distribution level.
Overview
About PCC Panels
A Power Control Centre sits at the head of the low-voltage distribution. It receives the incoming supply, usually from a transformer or generator, through an incomer breaker, and distributes it over a main busbar to outgoing feeders that supply sub-panels, MCCs and large loads. Because it carries the full load of the installation, its ratings, busbar system and protection coordination are fundamental to the safety and reliability of everything downstream.
Metering and protection at the incomer and on important feeders let operators see the loading and let faults be cleared close to where they occur. Prime Volt Systems builds PCC panels on a 415 V, 3-phase, 50 Hz system with ratings up to 6300 A, copper or aluminium busbars and IP42 to IP54 enclosures, to IS / IEC 61439. Short-circuit withstand and the other project values are confirmed for each job.
To quote this, please share
- Incoming source and its rating (transformer kVA or generator)
- System fault level at the panel
- Number and rating of the outgoing feeders
- Breaker type preference for the incomer and feeders (ACB or MCCB)
- Metering, protection and indication requirements
- Busbar material preference and any form of separation specified
- Indoor or outdoor location and the IP rating needed
PCC Panels
What you get
- 01Primary distribution and control
- 02Robust busbar system
- 03Flexible feeder arrangement
Specifications
Technical data
Values are confirmed per project and standard.
- 415 V, 3-phase, 50 Hz
- Up to 6300 A
- Confirmed per project
- IP42 to IP54
- Copper or aluminium
- Floor-standing or wall-mounted
- Powder-coated sheet steel (thickness per project)
- IS / IEC 61439
Components
- Incomer (ACB/MCCB)
- Main busbar
- Outgoing feeders
- Metering and protection
Features
- Primary distribution and control
- Robust busbar system
- Flexible feeder arrangement
Applications
- Industrial plants and factories
- Commercial and institutional buildings
- Infrastructure and utility projects
- Power distribution networks
